Ranch Panel

With clean lines and a classic appearance, Ranch Panel doors will be the envy of any neighborhood. Features distinctive long panels and incorporates the durability and energy efficiency that you’ll appreciate for years to come.

previous arrow
next arrow
Slider
Design Overview
  • Embossed pebble-grain texture
  • 11 window design options
  • Available in all nine Midland colors
  • Available decorative hardware



Construction Overview
  • 24-, 25- and 27-gauge exterior and interior steel panels
  • Available with or without insulation
  • Energy-efficient polyurethane, polystyrene and thermobond options result in exceptional R-Value
  • Heavy-duty galvanized hardware and track
  • Commercial-grade bottom weather seal with aluminum retainer
  • Grip-point compliant
  • Standard, 11-ball nylon rollers
  • Wind load certification available
RanchPanel
COLORS
WHITE
WHITE
ALMOND
ALMOND
SANDTONE
SANDTONE
TERA-BRONZE
TERA-BRONZE
GREEN
GREEN
COFFEE
COFFEE
ROSEWOOD*
ROSEWOOD*
LIGHT OAK*
LIGHT OAK*
DARK OAK*
DARK OAK*
BLACK
BLACK
GRAY***
GRAY***
COLORSELECT**
COLORSELECT**
*Not available in Series 24 **Available in ThermoSteel™ only. ***Available in ThermoGuard™ and TS-138 only. Due to the printing process, colors may vary.
Window Designs
PLAIN
PRAIRIE
SOMERTON
STOCKBRIDGE
STOCKTON
STOCKTON ARCH
2 PIECE SUNBURST
WAGON WHEEL
WYNDBRIDGE
CAMBRIDGE
FULLERTON
Decorative Hardware
standard garage door bracket
STANDARD STRAP
standard garage door handle
STANDARD HANDLE
GLASS
PLAIN
PLAIN
LOW E
LOW E
OBSCURE
OBSCURE
GRAY
GRAY
FROSTED*
FROSTED*
DOUBLE DARK*
DOUBLE DARK*
BRONZE
BRONZE

* Tempered only. All other glass is available in both tempered and untempered.

Construction & Insulation

From non-insulated doors to the industry-leading R-value of our ThermoGuard™ series, we have the perfect option for your home.



*For full warranty details contact your Midland dealer.
 ThermoGuard™ThermoSteel™TS-138Series 24
Foam/InsulatePolyurethanePolystyrenePolystyrenePlain Steel or T-Bond
Insulated*
R-Value18.09.257.50T-Bond = 7.0
U-Factor0.1360.2200.2640.376
Thickness2 inches2 inches1 3/8 inches2 inches
Exterior Steel27 gauge25 gauge27 gauge24 gauge
Interior Steel27 gauge25 gauge27 gaugeN/A
Warranty*
Excludes Springs		LifetimeLifetime25 YearsLifetime
CUSTOM WINDOW DESIGNS

Midland can perfectly match the style of your home by placing windows in any custom configuration. See you local Midland dealer to begin creating your custom door.

Long Window | Single Car (9×7)

24
30
25
31
26
32
27
28
29

Long Window | Double Car (16×7)

33
33
37
37
34
34
35
35
36
36
